Dyness
Dyness energy storage system Tower Pro TP11, 11.52 kWh
Product Code: OSA462
€2,869.00
incl. VAT
€3,207.00 You save €338.00
Dyness Tower Pro TP11 is an 11.52 kWh high-voltage LiFePO4 energy-storage tower made up of three modules. It provides 10.944 kWh of usable energy, and its IP55 construction is intended for indoor or suitably protected outdoor installation.
In stock
Not enough in stock.
Description
Dyness Tower Pro TP11 consists of three HV9640 LiFePO4 modules. Nominal system energy is 11.52 kWh, usable energy is 10.944 kWh, nominal voltage is 288 V, and the recommended depth of discharge is 95%.
Tower dimensions are 587 × 1009 × 310 mm and net weight is 150 kg. CAN, RS485, and RS232 are used for communication; the system can be expanded to up to 12 Tower Pro towers in parallel. Confirm the compatible inverter and installation solution against the manufacturer documentation.
Specifications
- Capacity: 11,52 kWh
- Voltage type: Aukšta įtampa (HV)
- Battery type: LiFePO4
- Usable capacity: 10,944 kWh
- Nominal voltage: 11,52 kWh
- Depth of Discharge (DoD): 95%
- Number of cycles / Service life: daugiau nei 8000 ciklų
- Number of modules: 3 × HV9640
- Protection Class (IP): IP55
- Operating temperature: nuo 0 °C iki +55 °C
- Connectivity: CAN, RS485, RS232
- Dimensions: 587 x 310 x 1009 mm
- Warranty: 10 years
